Curtain Side Semitrailer
We're here to help: Easy ways to get the answers you need.
Product Specification
|
Product Name |
Sliding curtain trailer |
|
Dimensions (Lx W x H) |
13000x2500x3600mm (can be customized) |
|
Payload |
60tons |
|
Axle |
3*13ton FUWA brand |
|
Suspension |
Mechanical suspension with 10/10/10 |
|
Main Beam |
Height:500mm, upper plate is 12mm, down plate is 14mm, middle plate is 8mm. Material: Q345B Steel |
|
Through beam and Side beam |
10# channel steel, 14 U shaped steel or channel steel |
|
Side wall height |
1600mm corrugated steel plate |
|
Platform thickness |
3mm-5mm /Q235steel |
|
Tire |
Triangle brand, 12R22.5 (12pcs) |
|
Traction Pin |
2"(50mm)or 3.5"(90mm)traction pin |
|
Landing Leg |
28T load landing leg |
|
Brake system |
Dual Line braking system/Optional ABS |
|
Brake chamber |
Six double chamber |
|
Electrical System |
24v, 7core socket, LED lights (suitable for all market) |
|
Painting |
Sandblasted, anti-rust chassis surface is available with 1 layer of anticorrosive primer and 2 layers of top coats |
|
Remark: All the products we can customize for you, if you have any inquiries about our products, please contact us, we will give you the most reasonable price, the most perfect service, the fastest delivery time and best products! |
|
